DELUGE - EBN
WET LOCATION POLYCARBONATE BATTERY UNIT
The EBN series of battery units is designed to operate in the most extreme environments. The unit, designed using a polycarbonate housing, maintains its sealed interior with a continuous integral gasket. The EBN series is available in 6VDC and 12VDC versions in 36W, 72W, 100W or 130W wattage capacity for a minimum of 30 minutes in emergency mode. Autotest feature is standard.
120/277/347 VAC 60 Hz input, field selectableHigh efficiency, rapid recovery, precision control charging systemMomentary push button test switchDiagnostic/pilot LED for AC ON and CHARGEFully automatic, current limited charger − Line latched, low voltage protectionBrownout and short circuit protectionMaintenance free, sealed lead acid batteryBlack or white polycarbonate housingCSA logo with C22.2 141-15CSA logo certified type 2 ,3, 3R, 4, 4X,5, 12 or 12KCSA logo certified to NSF 2
Environment
Wet
Light Source
Quartz Halogen,
LED
Material
Polycarbonate
Ratings
Nema 4X
Voltage
12V,
6V
Bridge
Yes
