EBWP
WEATHERPROOF NON-METALLIC BATTERY UNIT
The EBWP series of NEMA4X and EEMAC4X rated weatherproof battery units is designed to operate in the most extreme environments. The fully gasketed, reinforced, non-metallic housing features a hinged cover that secures with durable screw locks. The EBWP series is available in 6VDC, 12VDC and 24VDC versions in a range of wattage capacities between 36 and 720W, for 30 minutes duration.
- 120/347 VAC or 277 VAC, 60Hz Input
- High efficiency, rapid recovery, precision control charging system
- Momentary push button test switch
- Diagnostic/pilot LED for AC ON and CHARGE
- Fully automatic, current limiter charger − Line latched, low voltage protection
- Brownout and short circuit protection
- Maintenance free, sealed lead acid battery
- Non-Metallic Housing, grey finish standard
- CSA Certified to C22.2 141-15
Environment
Dry,
Wet
Fixture Type
Battery Units
Light Source
Quartz Halogen,
Quartz Sealed Beam,
Tungsten,
Tungsten Sealed Beam,
LED
Material
Polycarbonate
Ratings
Nema 4X
Voltage
12V,
24V,
6V
Bridge
Yes
